Petrol compact series
ACCESS J60-75
Suitable for transfers of clear and moderately charged water by accepting particles up to 6 mm. High-performance materials such as ceramic carbon mechanical lining and pressure-injected cast aluminum pump body offer a excellent skill and longevity.
Technicals characteristics
| Type of pump | Self-priming |
| Ø of the Suction Connector | 75 mm |
| Ø of the Discharge Connector | 75 mm |
| Maximum flow rate | 1000 L/min – 60 m3/h |
| Pressure | 2.8 bar |
| HMT (Height Manometric Total) | 28 m |
| Maximum Suction Height | 8 m |
| Grain size (Ø strainer hole) | 6 mm |
| Mechanical packing | Ceramic carbon |
| Engine | R210 – WORMS |
| Engine type | 4 Temps essence OHV |
| Fuel | Unleaded petrol 95 |
| Tank capacity | 3.6 L |
| Average autonomy | 1 h 26 |
| Dimensions L x W x H | 500 x 395 x 445 mm |
| Dimensions packed L x W x H | 520 x 425 x 455 mm |
| Net dry weight | 25 Kg |
| Gross weight packed | 26 Kg |
Standards equipments
- Startup Launcher
- Engine 4 Petrol or diesel time
- Self-priming
- Ceramic Carbon Mechanical Graniture
- Steel strainer, ball connections and clamps provided
